Chilled Water System Design – Nominal Conditions Breakdown
What is โNominal” Chilled Water Conditions?
The term “Nominal” used in various technical documentation, IOM manuals, and manufacturers data sheets defines the baseline parameters that ASHRAE, AHRI, and various manufacturers use to describe ideal conditions for comfort cooling.
This technical reference defines the standard baseline parameters for chilled water comfort cooling systems and explains the thermodynamic relationships between supply temperature, ฮT, and flow rate.
โ ๏ธ While these values represent the industry-standard starting points referred to in many design sheets, technical bulletins, and Installation manuals, the actual system specifications will often vary based on the specific application requirements. Always reference the design data sheet when performing a startup, or attempting to commission a system!
Nominal Chilled Water And Condenser Water Conditions:
- Supply Chilled Water Temperature (LWT): 44ยฐF
- Return Chilled Water Temperature (RWT): 54ยฐF
- Chilled Water Temperature Differential (ฮT): 10ยฐF
- Evaporator Flow Rate: 2.4 GPM per ton
- Entering Condenser Water Temp (ECWT): 85ยฐF
- Leaving Condenser Water Temp (LCWT): 95ยฐF
- Condenser Temperature Differential (ฮT): 10ยฐF
- Condenser Flow Rate: 3 GPM per ton
Chilled Water Side
44ยฐF Supply Temperature Rationale
The 44ยฐF leaving water temperature achieves three critical objectives:
- Dehumidification capability: Maintains coil surface temperature in the mid 40s, below the typical space dew points (~55ยฐF).
- Dual-load management: Addresses both sensible (temperature) and latent (humidity) cooling requirements
- Proven reliability: Validated across diverse comfort cooling applications by ASHRAE, AHRI, and various manufacturers.
Flow Rate Calculation: Why they use 2.4 GPM Per Ton
The 2.4 GPM per ton standard derives from fundamental heat transfer principles:
Heat Transfer Equation (Water Only):
- BTU/hr = 500 ร GPM ร ฮT
For 1 ton of cooling (12,000 BTU/hr) at ฮT = 10ยฐF (Water Only):
- GPM = 12,000 รท (500 ร 10) = 2.4 GPM/ton
Expanded flow calculation for various types of fluids:
- 12,000 BTU/hr รท 10ยฐF รท 1 BTU/lbยทยฐF รท 60 min/hr รท 8.34 lb/gal = 2.398 GPM
Chilled Water And DX System Comparison
Direct expansion (DX) evaporators in comfort cooling applications typically maintain a coil temp in the low to mid 40sยฐF and an 8โ12ยฐF suction superheat at the coil outlet. We are essentially trying to achieve the same cooling effect using the sensible heat exchange of water, rather than the Latent heat exchange of refrigerant at the indoor coil.
Chilled Water System Variations
Modern installations frequently deviate from baseline parameters for performance optimization, so it is important that you are always referencing the design data when performing a startup or commissioning. Some factors include:
Application-specific requirements: Data centers, cleanrooms, and industrial processes, are all custom tailored to meet their specific process needs in that climate.
High ฮT designs for energy efficiency (12โ18ยฐF Delta Systems): Reduced pumping energy, and via lower flow rates.
Variable chilled water supply temperature: Improved part-load chiller efficiency when additional cooling is not required.
Glycol systems for freeze protection: Glycol is thicker than water, and also has a lower specific heat than water.
Commissioning and Troubleshooting Protocol
โ ๏ธ Important first step: Always reference design documentation and specification sheets. If you are lucky, the startup guy left them in the panel. If you are not, you may have to source them yourself from the manufacturer, or 3rd party.
Proper system evaluation requires comparison against intended operating parameters. They take into consideration:
- Building load calculations
- Coil selection specifications
- Control sequence logic
- Space condition requirements
- Chiller operating envelope 365 days a year
They can help get you out of a bind from time to time, but troubleshooting against memorized baselines without verifying design intent leads to misdiagnosis.
Condenser Water Side
85ยฐF Entering Temperature Rationale
The 85ยฐF entering condenser water temperature represents a design condition based on:
- Typical cooling tower performance: Achievable leaving water temperature from cooling towers operating at design wet-bulb conditions (typically 78ยฐF wet-bulb, 5-7ยฐF cooling tower approach)
- Chiller efficiency optimization: Balances reasonable condenser pressures with practical cooling tower sizing
- Geographic applicability: Suitable for most North American comfort cooling applications during peak load conditions
Flow Rate Calculation: 3 GPM Per Ton
The 3 GPM per ton condenser water flow rate derives from the same heat transfer principles as chilled water, but accounts for higher heat rejection due to the heat of compression, and mechanical heat generated by the compressor:
Heat Transfer Equation:
BTU/hr = 500 ร GPM ร ฮTFor 1 ton of cooling capacity:
A chiller rejecting heat must handle both the cooling load (12,000 BTU/hr) plus the compressor work input.
The total heat rejection typically equals approximately 15,000 BTU/hr per ton (1.25 ร cooling capacity). This is called a “Cooling Tower Ton” in design literature.
1 Cooling tower Ton is = to 15,000 BTU’s
At ฮT = 10ยฐF:
GPM = 15,000 รท (500 ร 10) = 3.0 GPM/tonExpanded calculation:
15,000 BTU/hr รท 10ยฐF รท 1 BTU/lbยทยฐF รท 60 min/hr รท 8.34 lb/gal = 2.998 GPMRounded for field use: 3.0 GPM per ton
