Member Post posted an update July 14, 2026
19XR pic 2 controller
Hey any of you guy ever run on an 19XR with a PIC2 controller failling. It’s randomly shut down and then reboot work for a couple minutes sometimes hour and then do it all over again ? Any advice. We want to replace it with a MCS controller but its an OEM electronic starter so we’ll nees to replace the starter to put a Mcs controller. Did…
-
Member Post posted an update July 7, 2026
Looking for service manual
Looking to see if anyone has a current service manual for a York VSD HYP1278XHC30B46B.
Specifically disassembly of the pole assemblies for cleaning. Not having much luck finding anything
- View more comments
-
Member Post posted an update July 2, 2026
Hey guys, im having an issue with a 30hxc series 4. My oil pressure transducer for circuit A1 is reading 0 no matter what, we have voltage readings at the board which match A2. Also the board still reads 0 with transducer plug unhooked also shorted. I replaced the SCB board figuring it wasn’t working correctly but now thinking its the main board…
- View more comments
-
Member Post posted an update June 30, 2026
Summer 2026 blues
Hello everyone,
Just joined the community. Im longing for the days I can focus soley on large scale equipment. Looking forward to learning more here!
~Fred
- View more comments
-
Member Post posted an update June 14, 2026
Recover hose set up
Im recovering 4160Ib of R134a I have a recovery set up that works ok but I would like to see some other set ups, I know we are doing push and pull im just looking for hose set up
- View more comments
-
Member Post posted an update June 24, 2026
Carrier 19XR Frame 5 Compressor
Oil is leaking where the sump heater comes thru the compressor housing. There is a seal on the inside. Anyone know if the seal can be replaced if you remove the oil pump?
-
Member Post posted an update June 18, 2026
Does anyone have the manual to check the igbt and scr. On a yvaa. I looked in files and could not find it
- View more comments
-
Member Post posted an update January 21, 2026
Carrier AquaSnap
I have a 225 ton Carrier AquaSnap chiller at a metal processing plant. What is the best way plug into this chiller for service and diagnostics. Chiller has the scrolling marquee but its a pain in the ass to see all the parameters. The CCN software is obsolete. I believe it was service tool v5. Is there any new software to interface with the…
- View more comments
-
Member Post posted an update June 8, 2026
York YK Low Load Issues
Hey guys, looking for some insight from the York specialists in here on a 2012 vintage YK chiller. Got a couple of things I’m tweaking on it and wanted to see what your experiences have been.
1. Lowering Condenser Water Temp (VFD Control): I’m recommending replacement of a VFD on the tower fan to control head pressure. I’m looking to see how…
- View more comments
-
Member Post posted an update May 5, 2026
YCIV has 3 sensors on 1 circuit not reading, the voltages are fine to the board, but the display will not give me a value. The board is now obsolete and needs a retrofit. Any work around?
- View more comments
